Screed Floor Systems

Onix Plus™ Screed Base Unit

Onix Plus™ Screed Base Units are a unique, innovative solution to hard floor power and data distribution requirements

Overview

Onix Plus™ Screed Base Units are a unique, innovative solution to hard floor power and data distribution requirements in screed floors. The Base Units are installed prior to screeding. These are designed for use with the Cablelink Plus™ Screed Ducting System. Wiring space can also be reduced when used in shallow screed depths. Both require the use of a plate height adjustment kit. These are supplied with two metal trunking entry side plates as standard.

Features & Benefits:
  • 3 - Compartment floor Box - 265 x 265mm
  • Screeded Floor - Base Only
  • Disposable Screen lid provided to assist installation
  • Ideal for areas of high, heavy, Load Bearing requirements such as Car Showrooms and Exhibition Centres, etc.
  • Tested to EN50085-2-2 to accept 10,000N load
  • 35mm wiring space as standard
  • Supplied with 4 PVC Ducting side plates
  • Designed to support Cat 6 and Cat 7 structured cabling systems
  • If screed depth is 55mm, reduce wiring space to 25mm by use of suitable CUBA kit
  • Device plate can be adjusted to provide increased wiring space or greater plug top clearance
  • Designed for use with the Cablelink Plus™ Screed Ducting System
  • 265UK Version = Screed depth between 55 - 80mm
  • 265XUK Version = Screed depth between 80 - 110mm
Certifications:
  • Conforms to BS EN 50085-2-2:2008 (Clauses 10.3 and 10.5), BS EN 60670-1:2005, IEC 60670-23:2006
  • BS EN 60529:1992
  • Classification according to resistance to vertical load applied through small surface area 3000N
  • Classification according to resistance to vertical load applied through large surface area 10000N
  • Low Voltage Directive 2014/35/EU
  • RoHS Directive 2011/65/EU
  • CE Marked
  • Wet Washable IP Rating = IP44, when not in use
Specifications

Others

  • Brand
    • MK Electric
  • Installation Location
    • Indoor

Others

  • Brand
    • MK Electric
  • Installation Location
    • Indoor
  • Brand : MK Electric
  • Installation Location : Indoor
Sort
Document Title
Document Type
File Size
Product Number
Part Number
Description
Add to list
NXB265-2
Screed Base Unit, 265x265mm, 55-80mm Screed, 2 Compartments, 2 Blank Plates
NXB265-3
Screed Base Unit, 265x265mm, 55-80mm Screed, 3 Compartments, 2 Blank Plates
NXB265X-2
Screed Base Unit, 265x265mm, 80-110mm Screed, 2 Compartments, 2 Blank Plates
NXB265X-3
Screed Base Unit, 265x265mm, 80-110mm Screed, 3 Compartments, 2 Blank Plates
NXB265X-3CBE
265x265mm Floor Box 80-110mm Conduit
NXB340-3
Screed Base Unit, 340x340mm, 55-80mm Screed, 3 Compartments, 2 Blank Plates
NXB340-4
Screed Base Unit, 340x340mm, 55-80mm Screed, 4 Compartments, 2 Blank Plates
NXB340X-3
Screed Base Unit, 340x340mm, 80-110mm Screed, 3 Compartments, 2 Blank Plates
NXB340X-4
Screed Base Unit, 340x340mm, 80-110mm Screed, 4 Compartments, 2 Blank Plates
