Gateways
Gateway Ethernet
Ethernet gateway for MOD-BUS protocol management in TCP/IP
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
The H-GTW enables the integration of Notifier fire alarm control panels into supervisory/control systems integrating Modbus master connectivity, using the gateway of Notifier ID3000 / ID50 / ID60 / AM8200 fire alarm control panels from supervisory/control systems with Modbus master connectivity. Gateway works from the Modbus system's point of view, as a Modbus slave device, responding to data queries from the Modbus master, and from the Notifier system's point of view, as a serial device connected to its RS232 port, serving data received from the Notifier to the Modbus side.
Features & Benefits:- Environmental class: III
- Operating temperature range: -30 to + 85 C ̊
- Operating humidity: 0...75% non-condensing
- Main board external power supply: 5...30 VDC - 350 mA
- Communication method Via TCI/IP: with automatic detection
- Communication method RS-232: 4800 Bds to 115200 Bds
- RAM capacity: 256kbys
- Supported speed Via TCI/IP: 10/100Mbts/1Gbts
- Processor: Cortex M4
- 2014/30/EU General Electromagnetic Compatibility Directive
- 2014/35/EU Low Voltage Directive
- 2011/65/EU ROHS Directive
- 2014/53/EU RED Directive.
- EN 62368-1 Electrical safety for IT equipment
