    Plant & Integration Controllers

    IQ412 Controllers

    Trend IQ412 Controllers intelligent controllers are designed for use as unitary controllers in building control systems.

    Overview
    Trend IQ412 Controllers are designed for use as unitary controllers in building control systems. Full compatibility with other Trend IQ controllers enables the IQ41x to integrate the local environmental needs with the bulk air conditioning system in order to optimise both comfort and running costs. The IQ412 Controllers have 5 inputs (3 universal, 2 digital) and 6 outputs. The IQ412 has 4 solid state digital outputs and 2 analogue voltage outputs.

    The IQ412 Controllers uses Ethernet and TCP/IP networking technologies with embedded XML and is fully compatible with other Trend IQ controllers. Trend communications over a current loop LAN and support for BACnet over IP are available as options. A local PC or display (e.g. IQView4) can be connected to the RS232 port. A Wallbus port is also provided for use with room displays.

    Features & Benefits:
    • 11 on board I/O channels - 5 inputs and 6 outputs
    • Ethernet 10/100 Mbps main network with TCP/IP protocol
    • Trend current loop LAN option
    • Embedded XML Web Services as standard
    • BACnet over IP option
    Certifications:
    • certified as a BACnet Application Specific Controller
    • EN61326-1:2006
    • EN61010-1:2010
    • UL rated as ‘UL916’
    Specifications

    Others

    • Brand
      • Trend

    Others

    • Brand
      • Trend
    • Brand : Trend
    Name
    Date
    Size
    No Resources documents tagged to this product
    An error occurred . Please try after sometime
    Product Number
    Part Number
    Compare
    Description
    Leaf Category
    Thumbnail
    Add to list
    IQ412-1000U500000
    IQ41224VAC-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet (24Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1000U500000
    IQ41224VAC-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet (24Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1000U500200
    IQ412INT24VAC Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1000U500200
    IQ412INT24VAC Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1000U501000
    IQ412BAC24VAC-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet and BACnet IP (24Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1000U501000
    IQ412BAC24VAC-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet and BACnet IP (24Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1000U501200
    IQ412INTBAC24VAC Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1000U501200
    IQ412INTBAC24VAC Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1000U800000
    IQ412230-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet (230Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1000U800000
    IQ412230-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet (230Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1000U800200
    IQ412INT230 Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1000U800200
    IQ412INT230 Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1000U801000
    IQ412BAC230-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet and BACnet IP (230Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1000U801000
    IQ412BAC230-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet and BACnet IP (230Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1000U801200
    IQ412INTBAC230 Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1000U801200
    IQ412INTBAC230 Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1010U500000
    IQ412LAN24VAC-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet and Trend current loop Lan (24Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1010U500000
    IQ412LAN24VAC-IQ412 controller 4 DO 2 AO 3 UI 2 DI with Ethernet and Trend current loop Lan (24Vac) Datasheet TA201247.
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-trend-iq412-series-intelligent-controllers-primaryimage
    IQ412-1010U500200
    IQ412INTLAN24VAC Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
    IQ412-1010U500200
    IQ412INTLAN24VAC Trend IQ®412 Series Intelligent Controller, 10100 Mbps, 3 UI, 2 DI, 4 DO, 2 AO
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-IQ411-1000U500200
