Linear Actuators
M4100 Series Thermoelectric Actuators
The M4100 Series Thermoelectric Actuators are designed with efficacy to provide time-controlled two point regulation for heating and cooling systems.
Overview
The M4100 Series Thermoelectric Actuators provides time-controlled twopoint regulation of heating and cooling systems. They are used in room and zone applications such as fan coil units, radiators, floor heating systems, chilled ceilings, and convectors. The actuators are designed for applications where space is limited. The valve adapter assortment guarantees a perfect match of the actuator to almost all valve bottoms and heating circuit. The function display of the actuator shows at first glance whether the valve is open or closed; this can be also felt in the dark.Features & Benefits:
- No mounting tools are required
- Water protected housing design
- Noiseless operation
- Surge protection(2.5kV)
- Auxiliary switch models for driving pumps or fans
- EN 60730
Specifications
Others
- Brand
- CentraLine
Others
- Brand
- CentraLine
- Brand : CentraLine
Others
Name
Description
File Size
Date
Size
M4100E/K - Product Data (English)
application/pdf 443.72 KB
7/31/2023
443.72 KB
M4100E/K - Produktdaten (German)
application/pdf 459.34 KB
7/19/2023
459.34 KB
M4100E/K - Fiche Produit (French)
application/pdf 493.57 KB
7/19/2023
493.57 KB
M4100E/K - Installation Instructions (English)
application/pdf 608.39 KB
7/31/2023
608.39 KB
Name
Description
File Size
Date
Size
M4100E/K - Installation Instructions (English)
608.39 KB
7/31/2023
608.39 KB
Name
Description
File Size
Date
Size
M4100E/K - Installation Instructions (English)
608.39 KB
7/31/2023
Product Number
SKU
Description
M4100E1510
0-10Vdc Thermoelectric linear actuator, 24Vac, 2.5mm stroke, 100N, NC, 75s runtime, order cable separately
M4100K1515
0-10Vdc Thermoelectric linear actuator, 24Vdc, 2.5mm stroke, 100N, NC, 75s runtime, order cable separately
M4410C4000
Thermoelectric Actuator, 24V AC/DC, 100N, 5mm, Normally Open, Actuator Stem Retracts
M4410C4500
Thermoelectric Actuator, 24V AC/DC, 100N, 5mm, Normally Open, Actuator Stem Extends
M4410C4540
Thermoelectric Actuator, 24V AC/DC, 100N, 5mm, Normally Open, Actuator Stem Extends, Auxillary Switch
M4410E1510
M4410E1510 Thermoelectric Actuator, 24V AC, 100N, 4mm, Normally Closed, M44-VA10 adapter
M4410K1515
M4410K1515 Thermoelectric Actuator, 24V DC, 100N, 4mm, Normally Closed, M44-VA10 adapter
M4410L4000
Thermoelectric Actuator, 230V AC, 100N, 5mm, Normally Open, Actuator Stem Retracts
M4410L4500
Thermoelectric Actuator, 230V AC, 100N, 5mm, Normally Closed, Actuator Stem Extends
M4410L4540
Thermoelectric Actuator, 230V AC, 100N, 5mm, Normally Closed, Actuator Stem Extends, Auxillary Switch
SKU
Description
M4100E1510
0-10Vdc Thermoelectric linear actuator, 24Vac, 2.5mm stroke, 100N, NC, 75s runtime, order cable separately
M4100K1515
0-10Vdc Thermoelectric linear actuator, 24Vdc, 2.5mm stroke, 100N, NC, 75s runtime, order cable separately
M4410C4000
Thermoelectric Actuator, 24V AC/DC, 100N, 5mm, Normally Open, Actuator Stem Retracts
M4410C4500
Thermoelectric Actuator, 24V AC/DC, 100N, 5mm, Normally Open, Actuator Stem Extends
M4410C4540
Thermoelectric Actuator, 24V AC/DC, 100N, 5mm, Normally Open, Actuator Stem Extends, Auxillary Switch
M4410E1510
M4410E1510 Thermoelectric Actuator, 24V AC, 100N, 4mm, Normally Closed, M44-VA10 adapter
M4410K1515
M4410K1515 Thermoelectric Actuator, 24V DC, 100N, 4mm, Normally Closed, M44-VA10 adapter
M4410L4000
Thermoelectric Actuator, 230V AC, 100N, 5mm, Normally Open, Actuator Stem Retracts
M4410L4500
Thermoelectric Actuator, 230V AC, 100N, 5mm, Normally Closed, Actuator Stem Extends
M4410L4540
Thermoelectric Actuator, 230V AC, 100N, 5mm, Normally Closed, Actuator Stem Extends, Auxillary Switch
