SCS Series Smoke Control Expander Module
Honeywell's SCS series smoke control modules provides Notifier OYNX AFP-3030 panel and NCA-2 network annunciator capability to add a local or remote fire fan control panel for HVAC application.
Overview
Honeywell's SCS series smoke control modules provides Notifier OYNX AFP-3030 panel and NCA-2 network annunciator capability to add a local or remote fire fan control panel for HVAC application. Each SCS provides control and status indication for up to eight Fire Fans, Dampers or groups of Fans or Dampers. Smoke Control active indication and Reset input is also provided. One SCE Smoke Control Expander can be used with SCS expanding the capability to control and indicate for up to 16 switch groups. Up to 10 annunciator addresses are supported on NOTIFIER systems, providing a maximum capability to control and monitor 160 separate switch groups.
Features & Benefits:- Communicates via ACS bus and addresses via rotary decade switches
- Locking three-position switches
- Green, red and amber LED indication for Fan or damper status, The SCS-8 run LED blinks when Duct Probe is activated
- Integrated Smoke Control active indication and Reset input
- Custom labelling provided by slide-in label insert
- AS1670.1: 2018 section 7.15.
Specifications
Others
- Minimum Operating Voltage
- 20
- Maximum Operating Humidity
- 93 Percentage
- Minimum Operating Ambient Temperature
- 0 degree Celsius
- Maximum Operating Voltage
- 28
- Product Type
- Smoke Control Expander Module
- Regulatory Approvals
- AS1670.1: 2018 section 7.15
- Brand
- Honeywell
Others
- Minimum Operating Voltage
- 20
- Maximum Operating Humidity
- 93 Percentage
- Minimum Operating Ambient Temperature
- 0 degree Celsius
- Maximum Operating Voltage
- 28
- Product Type
- Smoke Control Expander Module
- Regulatory Approvals
- AS1670.1: 2018 section 7.15
- Brand
- Honeywell
- Minimum Operating Voltage : 20
- Maximum Operating Humidity : 93 Percentage
- Minimum Operating Ambient Temperature : 0 degree Celsius
- Maximum Operating Voltage : 28
- Product Type : Smoke Control Expander Module
- Regulatory Approvals : AS1670.1: 2018 section 7.15
- Brand : Honeywell
Others
Name
Description
File Size
Date
Size
Leaders in Life- Safety- Technology Catalogs
application/pdf 9.8 MB
1/8/2024
9.8 MB
SCS Series Smoke Control Station Data Sheet
application/pdf 205.54 KB
1/23/2024
205.54 KB
Notifier- AFP-3030 Series- fire alarm control panel Declaration of Conformity
application/pdf 383.68 KB
1/8/2024
383.68 KB
SCS Series Smoke Control Station Data Sheet
application/pdf 209.82 KB
1/8/2024
209.82 KB
Name
Description
File Size
Date
Size
Leaders in Life- Safety- Technology Catalogs
application/pdf 9.8 MB
1/8/2024
9.8 MB
SCS Series Smoke Control Station Data Sheet
application/pdf 205.54 KB
1/23/2024
205.54 KB
Notifier- AFP-3030 Series- fire alarm control panel Declaration of Conformity
application/pdf 383.68 KB
1/8/2024
383.68 KB
SCS Series Smoke Control Station Data Sheet
application/pdf 209.82 KB
1/8/2024
209.82 KB
Name
Description
File Size
Date
Size
Leaders in Life- Safety- Technology Catalogs
9.8 MB
1/8/2024
SCS Series Smoke Control Station Data Sheet
205.54 KB
1/23/2024
Notifier- AFP-3030 Series- fire alarm control panel Declaration of Conformity
383.68 KB
1/8/2024
SCS Series Smoke Control Station Data Sheet
209.82 KB
1/8/2024
Product Number
SKU
Description
SCE-8A
Smoke Control Module: Expander: 22-28V DC: 0C To 49C: Expands To 16 Switches
SKU
Description
SCE-8A
Smoke Control Module: Expander: 22-28V DC: 0C To 49C: Expands To 16 Switches
