PIR Motion Sensor

Designed for mid to high-end commercial environments where Grade 3 (IS3016A-1) or Grade 2 (IS3016-1) systems may be required, Honeywell anti-mask IS3016 series motion sensors deliver reliable protection and improved false alarm immunity through a total of four patented solutions.

IS3016 sensors are quick and easy to install featuring a simple, sleek design allowing quick and easy access to the connectors and an automatic plug-in connector. These sensors include an integrated end-of-Line (EOL) resistors for alarm as well as tamper loop and anti-mask already incorporate as well as an enhanced walk test function, further saving installation and setup time.

• Plug-in electronics designed for easy installation with an automatic plug-in connector
• High quality performance sensor meets the security approval requirements of high risk environments (EN Grade 3, NF & A2P, CPNI approval for UK Government Use)
• Infrared anti-mask technology on IS3016A-1 quickly detects intentional and accidental masks or blocks - sensor sends a trouble signal whenever it encounters mask conditions which significantly reduces the chance of any sensor security breaches
• Extensive detection coverage with extremely dense, wide and long detection range compared to similar products on the market to provide superior coverage
• Patented PIR signal analysis solution – the sensor looks for a wide time frame and integrates the signal received prior to any alarm triggering decision
• Patented mounting solution – to fix the sensor to the wall, the installer simply inserts the screw in the predefined location where it will be automatically held in place for easier and quicker installation

• NF&A2P 3 shields (NF324-H58 standard) and complies with EN50131-2-4 and RTC50131-2-4 standards; IP30 IK04
