    Controller Cables

    22 AWG Conductor

    22 AWG Conductors are Unshielded Plenum conductors which are stranded bare copper conductors.

    Overview

    22 AWG Conductors are Unshielded Plenum conductors which are stranded bare copper conductors. Connect-Air's commercial low voltage wire and cable is designed to support building automation systems (BAS), temperature controls (TC), security, fire/life safety, and Datacom applications. All cables are RoHS compliant and many are made in USA except import Category cables. These conductors are provided with Plenum Rated PVC insulation. It is used in Power limited control circuits.

    Features & Benefits:
    • Premium grade Plenum Rated PVC
    • Multiple jacket colours available consult sales office
    • Sequential footage markings to facilitate installation
    • Suitable for use from -20C to + 75C
    • Ripcord available consult Customer Service for details
    Certifications:
    • NEC Article 725 Type CL3P (UL: 75°C, 150V)
    • NEC Article 800 Type CMP (UL: 75°C, 300V)
    Specifications

    Others

    • Wire Size
      • 22 AWG
    • Brand
      • Alerton
    • Number of Cores
      • 3

    Others

    • Wire Size
      • 22 AWG
    • Brand
      • Alerton
    • Number of Cores
      • 3
    • Wire Size : 22 AWG
    • Brand : Alerton
    • Number of Cores : 3
    Product Number
    Part Number
    Compare
    Description
    Leaf Category
    Thumbnail
    Add to list
    W223C-1009PE
    Cable, 22AWG, 3-Conductor, Shielded, BlackWhiteRed Conductors, Black Jacket, LON Level 4
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-1009pe-22-awg-conductor-primaryimage
    W223C-1009PE
    Cable, 22AWG, 3-Conductor, Shielded, BlackWhiteRed Conductors, Black Jacket, LON Level 4
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-1009pe-22-awg-conductor-primaryimage
    W223C-2036B
    Connect-Air, Cable, 22AWG, 3-Conductor, Unshielded, Plenum, White Jacket, Box, 12lbs
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2036b-22-awg-conductor-primaryimage
    W223C-2036B
    Connect-Air, Cable, 22AWG, 3-Conductor, Unshielded, Plenum, White Jacket, Box, 12lbs
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2036b-22-awg-conductor-primaryimage
    W223C-2144B
    Connect-Air, Cable, 22AWG, 3-Conductor, Shielded, Plenum, White Jacket, Box, 16lbs
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2144b-22-awg-conductor-primaryimage
    W223C-2144B
    Connect-Air, Cable, 22AWG, 3-Conductor, Shielded, Plenum, White Jacket, Box, 16lbs
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2144b-22-awg-conductor-primaryimage
    W223C-2144FCBJC
    Cable, 22AWG, 3-Conductor, Shielded, Blue Jacket, Reel in Box, Field Controller Bus, 16lbs
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2144fcbjc-22-awg-conductor-primaryimage
    W223C-2144FCBJC
    Cable, 22AWG, 3-Conductor, Shielded, Blue Jacket, Reel in Box, Field Controller Bus, 16lbs
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2144fcbjc-22-awg-conductor-primaryimage
    W223C-2144FCM8
    Connect-Air, Cable, 22AWG, 3-Conductor, Shielded, Plenum, Blue Jacket, M8 Bag, Field Controller Bus
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2144fcm8-22-awg-conductor-primaryimage
    W223C-2144FCM8
    Connect-Air, Cable, 22AWG, 3-Conductor, Shielded, Plenum, Blue Jacket, M8 Bag, Field Controller Bus
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2144fcm8-22-awg-conductor-primaryimage
    W223C-2144WORRB
    Cable, 22AWG, 3-Conductor, Shielded, White Jacket with Orange Stripe, Reel in Box
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2144worrb-22-awg-conductor-primaryimage
    W223C-2144WORRB
    Cable, 22AWG, 3-Conductor, Shielded, White Jacket with Orange Stripe, Reel in Box
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2144worrb-22-awg-conductor-primaryimage
    W223C-2561ORRB
    Cable, 22AWG, 3-Conductor, 1.5 Pair, Shielded, Stranded, VFD, MSTP, Orange Jacket, Reel in Box
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2561orrb-22-awg-conductor-primaryimage
    W223C-2561ORRB
    Cable, 22AWG, 3-Conductor, 1.5 Pair, Shielded, Stranded, VFD, MSTP, Orange Jacket, Reel in Box
    https://honeywell.scene7.com/is/image/Honeywell65/hbt-bms-bms-w223c-2561orrb-22-awg-conductor-primaryimage
