    Enclosure Mounts & Hardware

    Cabinet

    This Cabinet selection provides a stylish and a classic accent to the décor of the facility lobby and the reception areas. The flexible back box design allows you to easily install and maintain the cabinets in a variety of building options.

    Overview

    These cabinets are designed to house Gamewell-FCI’s, E3 Series® Classic Emergency Voice Evacuation AA Series amplifiers, Honeywell Power Products’ Chassis Power Supplies. These cabinets are constructed from 16-gauge steel. The cabinet assembly consists of two parts: a back box and a solid, locking door. The key-locked door includes a pin-type hinge, two keys and hardware that are used to mount the door to the back box. The door offers optional right or left hinges to simplify the installation. The cabinet knockouts are positioned at numerous points, so that the Installer can bring a conduit into the enclosure. The cabinets are available in black and red. This selection provides a stylish and a classic accent to the décor of the facility lobby and the reception areas. The flexible back box design allows you to easily install and maintain the cabinets in a variety of building options.

    Features & Benefits:
    • Constructed of 16- gauge steel back box with integral trough offset
    • Includes a slotted quarter-turn latch and key lock
    • Offers a 90Deg opening door with zero clearance; 180° opening door with full clearance
    • Contains the back box and the door ground studs provide positive ground
    • Provides removable doors with zinc die-cast hinges
    Certifications:
    • UL Listed: S1869
    • FM Approved: 3022355
    • MEA Approved, Fire Dept. of New York: COA# 6077
    • CSFM: 7165-1703:0125
    • VMC Reference of Certification: VMA-45894-02C
    • ISO 9001 Certification
    Data Sheet
    Name
    Description
    File Size
    Date
    Size
    Cabinets - C4, D4 Data Sheet
    application/pdf 128.82 KB
    6/16/2023
    128.82 KB
    Output Controller Module Data Sheet
    application/pdf 558.77 KB
    5/14/2023
    558.77 KB
    E3 Series, Classic Data Sheet
    application/pdf 116.41 KB
    5/14/2023
    116.41 KB
    C4 and D4 Series Cabinets Data Sheet
    application/pdf 52.72 KB
    5/14/2023
    52.72 KB
    E3 Series Cabinets Data Sheet
    application/pdf 116.1 KB
    6/16/2023
    116.1 KB
    Name
    Description
    File Size
    Date
    Size
    Cabinets - C4, D4 Data Sheet
    application/pdf 128.82 KB
    6/16/2023
    128.82 KB
    Output Controller Module Data Sheet
    application/pdf 558.77 KB
    5/14/2023
    558.77 KB
    E3 Series, Classic Data Sheet
    application/pdf 116.41 KB
    5/14/2023
    116.41 KB
    C4 and D4 Series Cabinets Data Sheet
    application/pdf 52.72 KB
    5/14/2023
    52.72 KB
    E3 Series Cabinets Data Sheet
    application/pdf 116.1 KB
    6/16/2023
    116.1 KB
    Name
    Description
    File Size
    Date
    Size
    Cabinets - C4, D4 Data Sheet
    128.82 KB
    6/16/2023
    Output Controller Module Data Sheet
    558.77 KB
    5/14/2023
    E3 Series, Classic Data Sheet
    116.41 KB
    5/14/2023
    C4 and D4 Series Cabinets Data Sheet
    52.72 KB
    5/14/2023
    E3 Series Cabinets Data Sheet
    116.1 KB
    6/16/2023
    Product Number
    Part Number
    Description
    Add to list
    FCI-DR-C4B
    Cabinet: Door: Lock And Key For SBB-C4: Black
    FCI-DR-C4BR
    Blank door, PK-625 lockset, for 3 chassis back box, red
    FCI-DR-D4B
    Cabinet: Door: Lock And Key For SBB-D4: Black
    FCI-DR-D4BR
    Blank door, PK-625 lockset, for 4 chassis back box, red
