Current Sensors
Current Transducer
Hawkeye H421 analog current transducers provide reliable load trending information for large motor loads (up to 2400 A), with a proportional 4 to 20 mA signal.
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
Hawkeye H421 analog current transducers provide reliable load trending information for large motor loads (up to 2400 A), with a proportional 4 to 20 mA signal. The H421 versions include a span potentiometer that allows each sensor to be calibrated for maximum resolution.
Features & Benefits:- Split-core design for easy installation and fast retrofits
- No need for external CTs on large conductors
- Large openings for heavy conductors
- Loop powered 4 to 20 mA output
- 2-wire design reduces wiring cost
- Zero and span adjustments for field flexibility
- 30 mA at 12 to 30 V DC sensor power
- Lead-free
- UL
- CE
Specifications
Others
- Output Signal
- 4 - 20 milliampere
- Maximum Operating Humidity
- 90 (Non-Condensing) percentage relative humidity
- Minimum Operating Humidity
- 10 (Non-Condensing) percentage relative humidity
- Maximum Operating Ambient Temperature
- 140 degree Fahrenheit
- 60 degree Celsius
- Minimum Operating Ambient Temperature
- -15 degree Celsius
- 5 degree Fahrenheit
- Includes
- Span Potentiometer foot
- Product Type
- Current Transducer Degrees Celsius
- Brand
- Alerton
Others
- Output Signal
- 4 - 20 milliampere
- Maximum Operating Humidity
- 90 (Non-Condensing) percentage relative humidity
- Minimum Operating Humidity
- 10 (Non-Condensing) percentage relative humidity
- Maximum Operating Ambient Temperature
- 140 degree Fahrenheit
- 60 degree Celsius
- Minimum Operating Ambient Temperature
- -15 degree Celsius
- 5 degree Fahrenheit
- Includes
- Span Potentiometer foot
- Product Type
- Current Transducer Degrees Celsius
- Brand
- Alerton
- Output Signal : 4 - 20 milliampere
- Maximum Operating Humidity : 90 (Non-Condensing) percentage relative humidity
- Minimum Operating Humidity : 10 (Non-Condensing) percentage relative humidity
- Maximum Operating Ambient Temperature : 140 degree Fahrenheit|60 degree Celsius
- Minimum Operating Ambient Temperature : -15 degree Celsius|5 degree Fahrenheit
- Includes : Span Potentiometer foot
- Product Type : Current Transducer Degrees Celsius
- Brand : Alerton
Product Number
Please sign in to view part numbers available for purchase based on your account Sign In
Part Number
Compare
Description
Leaf Category
Thumbnail
Add to list
V-H221
Current Transducer, Split Core,0‐300AAC,4‐20mA, Loop Powered
V-H221
Current Transducer, Split Core,0‐300AAC,4‐20mA, Loop Powered
V-H221SP
Current Transducer, Split-Core, 0 to 300A, 4 to 20mA, Loop Powered
V-H221SP
Current Transducer, Split-Core, 0 to 300A, 4 to 20mA, Loop Powered
V-H321
Current Transducer, Split-Core, 0 to 300A, 4 to 20mA, Adjustable Calibration
V-H321
Current Transducer, Split-Core, 0 to 300A, 4 to 20mA, Adjustable Calibration
V-H321SP
Current Transducer, Split-Core, 0 to 800A, 4 to 20mA, Loop Powered
V-H321SP
Current Transducer, Split-Core, 0 to 800A, 4 to 20mA, Loop Powered
V-H421
Current Transducer, Split-Core, 0 to 800A, 4 to 20mA, Adjustable Calibration
V-H421
Current Transducer, Split-Core, 0 to 800A, 4 to 20mA, Adjustable Calibration
V-H421SP
Current Transducer, Split-Core, 0 to 1200A, 4 to 20mA, Loop Powered
V-H421SP
Current Transducer, Split-Core, 0 to 1200A, 4 to 20mA, Loop Powered
