Control Modules

Velociti® Series Addressable Audio Evacuation Module

Velociti® Series addressable audio evacuation modules control the communications between the command center and the telephone jacks/warden stations.

Velociti® Series addressable audio evacuation modules control the communications between the command center and the telephone jacks/warden stations. Wiring to individual telephone jacks and handsets is supervised and may be configured as 2-wire (Class B) or fault tolerant (Class A). Status is reported to the panel as normal, trouble, or telephone. The modules contain a panel-controlled LED indicator.

Addressable audio evacuation modules are installed in the signaling line circuit (SLC) of the Gamewell-FCI® emergency voice evacuation systems. Addressable audio evacuation modules are designed to fit into a 4-inch (10.16 cm) square junction box. The Velociti® Series use a communication protocol that substantially increases the speed of communication between the SLC devices and certain Gamewell-FCI analog addressable fire alarm controls. These devices operate in a grouped fashion. If one of the devices in the group has a status change, the panel’s microprocessor stops the group poll and concentrates on the single device. The net result is a superior response speed up to five times greater than earlier designs.

Features & Benefits:
  • Listed under UL® Standard UL 864 and UL2572 for mass notification
  • Designed as a compact size to allow easy installation
  • Includes a bi-color LED that flashes green whenever the module is addressed, and lights steady red upon activation*
  • * Only the red LED is operative in panels that do not operate in Velociti mode
Certifications:
  • UL: S1949, 2572 for Mass Notification
  • FM: 3023594
  • MEA FDNY: 227-03-E, Vol. IV
  • CSFM: 7300-1703:0107
  • ISO 9001 Certification

Others

  • Normal Input Current
    • 2.4 milliampere
  • Maximum Operating Humidity
    • 0.93
  • Alarm Current
    • 7.5 milliampere
  • Maximum Operating Voltage
    • 15 - 32 DC volt
    • 15 VDC
  • Minimum External Power Supply Voltage
    • 24 VDC
  • For Use With
    • Firefighter Phones/Jacks
  • Supported Wiring Configuration
    • Class B
  • Brand
    • Gamewell-FCI
  • Maximum IDC Wiring Resistance
    • 50 Ohms

Others

  • Normal Input Current
    • 2.4 milliampere
  • Maximum Operating Humidity
    • 0.93
  • Alarm Current
    • 7.5 milliampere
  • Maximum Operating Voltage
    • 15 - 32 DC volt
    • 15 VDC
  • Minimum External Power Supply Voltage
    • 24 VDC
  • For Use With
    • Firefighter Phones/Jacks
  • Supported Wiring Configuration
    • Class B
  • Brand
    • Gamewell-FCI
  • Maximum IDC Wiring Resistance
    • 50 Ohms
  • For Use With : Firefighter Phones/Jacks
  • Supported Wiring Configuration : Class B
  • Brand : Gamewell-FCI
  • Maximum IDC Wiring Resistance : 50 Ohms
  • Normal Input Current : 2.4 milliampere
  • Maximum Operating Humidity : 0.93
  • Alarm Current : 7.5 milliampere
  • Maximum Operating Voltage : 15 - 32 DC volt|15 VDC
  • Minimum External Power Supply Voltage : 24 VDC
