Smoke Detectors
Notifier NP-200 Series Photoelectric Smoke Detector
Notifier NP-200 Series Photoelectric Smoke Detector is unique optical sensing chamber is engineered to sense smoke produced by a wide range of combustion sources.
Overview
The Notifier NP-200 Series intelligent plug-in smoke detectors are designed for both performance and aesthetics, and are direct replacements for the NP-100 Series.A new modern, sleek, contemporary design and enhanced optical sensing chamber is engineered to sense smoke produced by a wide range of combustion sources in accordance with more stringent code standards. Exclusively for use with NOTIFIER’s Fire Warden Series addressable fire alarm control panels, the NP-200 Series point ID capability allows each detector’s address to be set with rotary, decimal address switches, providing exact detector location for emergency personnel to quickly locate a fire during its early stages, potentially saving precious rescue time while also reducing property damage. Two LEDs on each sensor light to provide a local, visible sensor indication. The NP-200 Series also offers 135F (57C) fixed temperature thermal sensing on the NP-200T and a remote test capable detector on the NP-200R for use with DNR(A)/DNRW duct smoke detector housings.Features & Benefits:
- Sleek, low-profile design
- Available in both Bright White (for new installations) and Ivory (for legacy installations)
- Photoelectric smoke detection
- Analog communications
- Low standby current
- Rotary address switches
- Dual LEDs for 360° visibility
- UL/ULC Listing: S1115
- FM Approved
- CSFM: 7272-0028:0503
Specifications
Others
- Maximum Standby Current
- 200 µA @ 24 voltage direct current
- Maximum Operating Voltage
- 15 - 32 (Peak) voltage direct current
- Minimum Operating Humidity
- 10 Percentage
- Maximum Operating Humidity
- 93 Percentage
- Brand
- Notifier
- System Sensor
- Material
- Plastic
- Sensitivity
- 0.5 - 3.5
- 0.5 - 4
- Detection Sensor Type
- Photoelectric
- Wiring Type
- 2-Wire
- Conventional or Addressable
- Addressable
Others
- Maximum Standby Current
- 200 µA @ 24 voltage direct current
- Maximum Operating Voltage
- 15 - 32 (Peak) voltage direct current
- Minimum Operating Humidity
- 10 Percentage
- Maximum Operating Humidity
- 93 Percentage
- Brand
- Notifier
- System Sensor
- Material
- Plastic
- Sensitivity
- 0.5 - 3.5
- 0.5 - 4
- Detection Sensor Type
- Photoelectric
- Wiring Type
- 2-Wire
- Conventional or Addressable
- Addressable
- Maximum Standby Current : 200 µA @ 24 voltage direct current
- Maximum Operating Voltage : 15 - 32 (Peak) voltage direct current
- Minimum Operating Humidity : 10 Percentage
- Maximum Operating Humidity : 93 Percentage
- Brand : Notifier|System Sensor
- Material : Plastic
- Sensitivity : 0.5 - 3.5|0.5 - 4
- Detection Sensor Type : Photoelectric
- Wiring Type : 2-Wire
- Conventional or Addressable : Addressable
Product Number
SKU
Description
NP-200
INTELLIGENT ADDRESSABLE PHOTO DETECTOR, WITH BASE; WHITE
NP-200-IV
Smoke detector, Ivory, Low-Profile Intelligent Photoelectric Sensor
NP-200R
REMOTE TEST CAPABLE INTELLIGENT ADDRESSABLE PHOTO DETECTOR; FOR USE WITH DNR(W) DUCT DETECTOR HOUSING; WHITE
NP-200R-IV
Photoelectric Smoke Detector: 15-32V DC: 4.5 mA max: White
SKU
Description
NP-200
INTELLIGENT ADDRESSABLE PHOTO DETECTOR, WITH BASE; WHITE
NP-200-IV
Smoke detector, Ivory, Low-Profile Intelligent Photoelectric Sensor
NP-200R
REMOTE TEST CAPABLE INTELLIGENT ADDRESSABLE PHOTO DETECTOR; FOR USE WITH DNR(W) DUCT DETECTOR HOUSING; WHITE
NP-200R-IV
Photoelectric Smoke Detector: 15-32V DC: 4.5 mA max: White
