Differential Pressure Switch
DBL Series Differential Pressure Switches are adjustable vacuum, pressure and differential pressure switches designed for both HVAC and energy management applications.
Overview
The DBL Series Differential Pressure Switches are adjustable vacuum, pressure and differential pressure switches designed for both HVAC and energy management applications. They can be used to sense either positive or differential air pressures.
The DBL pressure switches are compact and easy to install, since they have an internal, linearly scaled set point knob with an adjustable switching differential.
They will save installation time and money due to the ease of the calibration and adjustment procedures. A manometer is not necessary but can be used to verify the overall operation of the switches.
Specifications
Others
- Connection Size
- 1/2 inch
- Minimum Storage Temperature
- -20 degree Celsius
- -4 degree Fahrenheit
- Maximum Storage Temperature
- 185 degree Fahrenheit
- 85 degree Celsius
- Minimum Operating Ambient Temperature
- -20 degree Celsius
- -4 degree Fahrenheit
- Maximum Operating Ambient Temperature
- 185 degree Fahrenheit
- 85 degree Celsius
- Switch Configuration
- SPDT
- Pressure Sensor Type
- Differential
- Mounting Type
- Surface inch
- Connection Type
- NPT
- Pressure Type
- Differential
- Brand
- Alerton
Others
- Connection Size
- 1/2 inch
- Minimum Storage Temperature
- -20 degree Celsius
- -4 degree Fahrenheit
- Maximum Storage Temperature
- 185 degree Fahrenheit
- 85 degree Celsius
- Minimum Operating Ambient Temperature
- -20 degree Celsius
- -4 degree Fahrenheit
- Maximum Operating Ambient Temperature
- 185 degree Fahrenheit
- 85 degree Celsius
- Switch Configuration
- SPDT
- Pressure Sensor Type
- Differential
- Mounting Type
- Surface inch
- Connection Type
- NPT
- Pressure Type
- Differential
- Brand
- Alerton
- Connection Size : 1/2 inch
- Minimum Storage Temperature : -20 degree Celsius|-4 degree Fahrenheit
- Maximum Storage Temperature : 185 degree Fahrenheit|85 degree Celsius
- Minimum Operating Ambient Temperature : -20 degree Celsius|-4 degree Fahrenheit
- Maximum Operating Ambient Temperature : 185 degree Fahrenheit|85 degree Celsius
- Switch Configuration : SPDT
- Pressure Sensor Type : Differential
- Mounting Type : Surface inch
- Connection Type : NPT
- Pressure Type : Differential
- Brand : Alerton
Product Number
SKU
Description
DBL-205
Differential Pressure Switch, SPDT, 0.16 to 0.4wc
DBL-205A
Differential Pressure Switch, SPDT, 0.16 to 0.8wc
DBL-205D
Differential Pressure Switch, SPDT, 0.8 to 4wc
DBL-205E
Differential Pressure Switch, SPDT, 2 to 10wc
DBL-205L
Differential Pressure Switch, SPDT, 0.08 to 0.8wc
SKU
Description
DBL-205
Differential Pressure Switch, SPDT, 0.16 to 0.4wc
DBL-205A
Differential Pressure Switch, SPDT, 0.16 to 0.8wc
DBL-205D
Differential Pressure Switch, SPDT, 0.8 to 4wc
DBL-205E
Differential Pressure Switch, SPDT, 2 to 10wc
DBL-205L
Differential Pressure Switch, SPDT, 0.08 to 0.8wc
