Globe Valves

2-way Control Valve

The 2-way Control Globe Valves are a complete series of single-seated straight through globe control valves PN16. They are suitable for heating, ventilation and air conditioning systems (HVAC).

The 2-way Control Globe Valves are a complete series of single-seated straight through globe control valves PN16. They are suitable for heating, ventilation and air conditioning systems (HVAC). There are different order numbers for the 2-way straight through valve of the type V5011R. Depending on the flow capacity and the valve size, vary the last four digits of the order number.

Features & Benefits:
  • Brass body with internal threaded end connections
  • Low seat leakage rate
  • Self-adjusting packing
  • Accurate positioning to ensure state-of-the-art temperature control
  • Directly-coupled electric and pneumatic actuators for easy mounting
Certifications:
  • ISO228

Others

  • Media Temperature Range
    • 120 - 170 °C @ 1490 kPa
    • 2 - 120 °C @ 1600 kPa
  • Brand
    • CentraLine
  • Nominal Pressure
    • PN16
  • Valve Series
    • V5011R/S
  • Port Connection
    • Internal Thread
  • Actuator Stroke Length
    • 20 millimetre

Others

  • Media Temperature Range
    • 120 - 170 °C @ 1490 kPa
    • 2 - 120 °C @ 1600 kPa
  • Brand
    • CentraLine
  • Nominal Pressure
    • PN16
  • Valve Series
    • V5011R/S
  • Port Connection
    • Internal Thread
  • Actuator Stroke Length
    • 20 millimetre
  • Brand : CentraLine
  • Nominal Pressure : PN16
  • Valve Series : V5011R/S
  • Port Connection : Internal Thread
  • Actuator Stroke Length : 20 millimetre
  • Media Temperature Range : 120 - 170 °C @ 1490 kPa|2 - 120 °C @ 1600 kPa
Data Sheet
Name
Description
File Size
Date
Size
Internal Threaded End-Connection Linear valve PN16
application/pdf 153.78 KB
2/17/2022
153.78 KB
Name
Description
File Size
Date
Size
Internal Threaded End-Connection Linear valve PN16
153.78 KB
2/17/2022
153.78 KB
SKU
Description
alt
V5011R1083
V5011R1083 Control Valve, 2-way, PN 16, DN 40, kvs 25
alt
V5011R1075
V5011R1075 Control Valve, 2-way, PN 16, DN 32, kvs 16
alt
V5011R1059
V5011R1059 Control Valve, 2-way, PN 16, DN 20, kvs 6.3
alt
V5011R1026
Control Valve, 2-way, PN16, DN15, 2 to 150C, 1600kPa, 600N, 1.6Kvs
alt
V5011R1091
V5011R1091 Control Valve, 2-way, PN 16, DN 50, kvs 40
alt
V5011R1042
V5011R1042 Control Valve, 2-way, PN 16, DN 15, kvs 4.0
alt
V5011R1034
V5011R1034 Control Valve, 2-way, PN 16, DN 15, kvs 2.5
alt
V5011R1067
V5011R1067 Control Valve, 2-way, PN 16, DN 25, kvs 10
alt
V5011R1018
Control Valve, 2-way, PN16, DN15, 2 to 150C, 1600kPa, 600N, 1.0Kvs
alt
V5011R1000
Control Valve, 2-way, PN16, DN15, 2 to 150C, 1600kPa, 600N, 0.63Kvs
