Manual Call Points/Pull Stations

BG-8 Manual Pull Station

BG-8 Manual Pull Stations from Fire-Lite Alarms are metal pull stations that offers a single-action, normally-open contact alarm initiating point for use with UL listed Fire Alarm Control Panels.

BG-8 Manual Pull Stations from Fire-Lite Alarms are metal pull stations that offers a single-action, normally-open contact alarm initiating point for use with UL listed Fire Alarm Control Panels. The stations features a non- break-glass operation. They are operated by a pull on the pull cover. This causes a key latch to act against a retaining mechanism until adequate force is applied to open the station. As the station opens, a switch is released to initiate an alarm. The retainer in Model BG-8 is a permanent, high-tensile, flat spring, which eliminates the need for a glass retainer. When so operated, the cover hangs down (and cannot be reset without use of a reset key) indicating that the station was used to initiate an alarm.

Features & Benefits:
  • Complies with Americans with Disabilities Act
  • Sturdy metal construction
  • Simple operation
  • Operation does not require replacement of parts
  • Drawing of flames on cover helps communicate purpose of this device to people who do not read English words
  • Designed to prevent false alarms when bumped, shaken, or jarred
Certifications:
  • UL Listed
  • ULC Listed
  • California State Fire Marshal
  • MEA
  • ADA
  • ISO 9001

Others

  • Material
    • Aluminum
  • Brand
    • Fire-Lite

Others

  • Material
    • Aluminum
  • Brand
    • Fire-Lite
  • Material : Aluminum
  • Brand : Fire-Lite
Brochure
Name
Description
File Size
Date
Size
Fire-Lite Product Brochure
application/pdf 4.28 MB
4/29/2022
4.28 MB
Product Line Brochure (FL-4)
application/pdf 1 MB
4/29/2022
1 MB
Addressable Fire Alarm Control Panels
application/pdf 4.31 MB
4/29/2022
4.31 MB
Notices
Name
Description
File Size
Date
Size
Lite-Configurator 2.5 Readme File
application/pdf 205.08 KB
4/29/2022
205.08 KB
Name
Description
File Size
Date
Size
Fire-Lite Product Brochure
4.28 MB
4/29/2022
4.28 MB
Product Line Brochure (FL-4)
1 MB
4/29/2022
1 MB
Lite-Configurator 2.5 Readme File
205.08 KB
4/29/2022
205.08 KB
Addressable Fire Alarm Control Panels
4.31 MB
4/29/2022
4.31 MB
SKU
Description
alt
BG-8
Manual Pull Station, Single-Action, N/O Contact, 1/8in, 1A, 30V AC, 30V DC, Satin Finish, Aluminium
