Temperature Sensors
Dwyer Outdoor Temperature Sensor
Dwyer Outdoor Temperature Sensors offers different configurations to increase measurement accuracy by reducing radiated heat effects.
Overview
Dwyer Outdoor Temperature Sensors offers different configurations to increase measurement accuracy by reducing radiated heat effects for applications where the north side of the building is accessible, the TEOND/TE-OSA can be used to protect against low levels of radiated heat. If the sensor must be mounted in direct sunlight or a more precise measurement is required, our six plate radiation shield mounts over the temperature probe. The TE-RND radiation shield models can be surface or pipe mounted. All models include removable terminal blocks to simplify wiring.
Features & Benefits:- Weatherproof for outdoor installation
- Radiation shield available to eliminate heating effects following installation in direct sunlight
- Terminal connector eliminates need for wire nuts
- Building automation
- Outdoor temperature reference
Specifications
Others
- Minimum Operating Ambient Temperature
- -40 degree Fahrenheit
- -40 degree Celsius
- Maximum Operating Ambient Temperature
- 150 degree Celsius
- 302 degree Fahrenheit
- Product Type
- Sensor Degrees Celsius
- Brand
- Alerton
Others
- Minimum Operating Ambient Temperature
- -40 degree Fahrenheit
- -40 degree Celsius
- Maximum Operating Ambient Temperature
- 150 degree Celsius
- 302 degree Fahrenheit
- Product Type
- Sensor Degrees Celsius
- Brand
- Alerton
- Minimum Operating Ambient Temperature : -40 degree Fahrenheit|-40 degree Celsius
- Maximum Operating Ambient Temperature : 150 degree Celsius|302 degree Fahrenheit
- Product Type : Sensor Degrees Celsius
- Brand : Alerton
Product Number
Please Sign In to view part numbers available for purchase based on your account
Part Number
Description
Leaf Category
Thumbnail
Add to list
TE-OND-B
Temperature Sensor, Outside Air, 10K ohm Type II Thermistor, IP65
TE-OND-B
Temperature Sensor, Outside Air, 10K ohm Type II Thermistor, IP65
TE-OND-C
Temperature Sensor, Outside Air, 3K ohm Thermistor, IP65
TE-OND-C
Temperature Sensor, Outside Air, 3K ohm Thermistor, IP65
TE-OSA-A
Temperature Sensor, Outside Air, 10K ohm Type III Thermistor, IP54
TE-OSA-A
Temperature Sensor, Outside Air, 10K ohm Type III Thermistor, IP54
TE-OSA-B
Temperature Sensor, Outside Air, 10K ohm Type II Thermistor, IP54
TE-OSA-B
Temperature Sensor, Outside Air, 10K ohm Type II Thermistor, IP54
TE-OSA-C
Temperature Sensor, Outside Air, 3K ohm Thermistor, IP54
TE-OSA-C
Temperature Sensor, Outside Air, 3K ohm Thermistor, IP54
TE-OSA-D
Temperature Sensor, Outside Air, PT100 ohm RTD, IP54
TE-OSA-D
Temperature Sensor, Outside Air, PT100 ohm RTD, IP54
TE-OSA-E
Temperature Sensor, Outside Air, PT1000 ohm RTD, IP54
TE-OSA-E
Temperature Sensor, Outside Air, PT1000 ohm RTD, IP54
TE-OSA-F
Temperature Sensor, Outside Air, 20K ohm Thermistor, IP54
TE-OSA-F
Temperature Sensor, Outside Air, 20K ohm Thermistor, IP54
TE-OSA-Q
Temperature Sensor, Outside Air, 10K ohm Type III Thermistor, 11K ohm Shunt, IP54
TE-OSA-Q
Temperature Sensor, Outside Air, 10K ohm Type III Thermistor, 11K ohm Shunt, IP54
TE-RND-B
Temperature Sensor, Outside Air, 10K ohm Type II Thermistor, Radiation Shield, IP65
TE-RND-B
Temperature Sensor, Outside Air, 10K ohm Type II Thermistor, Radiation Shield, IP65
