    Duct Detectors

    SK-DUCT Intelligent Air Duct Smoke Detector

    SK-DUCT intelligent air duct smoke detectors are used for detecting smoke and products of combustion present in air moving through an HVAC air handling system.

    Overview

    SK-DUCT intelligent air duct smoke detectors are used for detecting smoke and products of combustion present in air moving through an HVAC air handling system. When smoke is detected in a duct, the unit communicates the condition to the HoneywellSilent Knight®control panel. The panel, in turn, depending on programming and wiring, turns off fans, blowers, and other devices. Intelligent air duct smoke detectorsutilize photoelectric technology for the detection of smoke. They provide early detection of smoke and products of combustion present in air moving through HVAC ducts in commercial and industrial applications. Intelligent air duct smoke detectorsare in a heavy duty gray steel backbox with a clear cover. They feature a pivoting housing that fits both square and rectangular footprints capable of mounting to a round or rectangular duct. They install quickly and easily. The unit senses smoke in the most challenging conditions, operating in airflow speeds of 100 to 4000 ft per minute, temperatures of -4° to 158° F, and a humidity range of 0 to 95% (non-condensing).

    Features & Benefits:
    • Versatile mounting options: square or rectangular configuration
    • Photoelectric, integrated low-flow technology
    • Air velocity rating from 100 ft/min – 4,000 ft/min (05 m/s – 2032 m/s)
    • Broad ranges for operating temperature (- 4°F – 158°F, -20°C – 70°C) and humidity (0% – 93% non-condensing)
    • Increased wiring space with a newly added 3/4" conduit knockout
    • Easily accessible code wheels on sensor head (included with SK-DUCT-W)
    • Clear cover for convenient visual inspection (SK-DUCT-W only)
    • Remote testing capability
    • Requires com line power only
    • Housing accommodates an addressable relay module, sold separately, for applications requiring a Form-C relay
    • New cover tamper signal
    Certifications:
    • UL Listed
    Specifications

    Others

    • Brand
      • Silent Knight
      • System Sensor

    Others

    • Brand
      • Silent Knight
      • System Sensor
    • Brand : Silent Knight|System Sensor
    Others
    Name
    Description
    File Size
    Date
    Size
    SK-DUCT BIM File
    application/x-tika-msoffice 1.31 MB
    1.31 MB
    SK-DUCT-W BIM File
    application/x-tika-msoffice 740 KB
    740 KB
    SK-DUCT analog photoelectric duct smoke detector housings CSFM Listing
    application/pdf 165.75 KB
    5/14/2023
    165.75 KB
    Sales Sheet
    Name
    Description
    File Size
    Date
    Size
    IntelliKnight System Sensor Device Sell Sheet
    application/pdf 266.36 KB
    6/23/2022
    266.36 KB
    Installation Instructions
    Name
    Description
    File Size
    Date
    Size
    SK-Duct Addressable Photoelectric Duct Detector Manual
    application/pdf 1.05 MB
    5/8/2023
    1.05 MB
    Data Sheet
    Name
    Description
    File Size
    Date
    Size
    IntelliKnight System Sensor Device Specification Data Sheet
    application/pdf 266.36 KB
    5/14/2023
    266.36 KB
    SK-DUCT Intelligent Air Duct Smoke Detector-Data Sheet
    application/pdf 145.44 KB
    5/14/2023
    145.44 KB
    Name
    Description
    File Size
    Date
    Size
    IntelliKnight System Sensor Device Sell Sheet
    application/pdf 266.36 KB
    6/23/2022
    266.36 KB
    SK-DUCT BIM File
    application/x-tika-msoffice 1.31 MB
    1.31 MB
    SK-DUCT-W BIM File
    application/x-tika-msoffice 740 KB
    740 KB
    SK-Duct Addressable Photoelectric Duct Detector Manual
    application/pdf 1.05 MB
    5/8/2023
    1.05 MB
    SK-DUCT analog photoelectric duct smoke detector housings CSFM Listing
    application/pdf 165.75 KB
    5/14/2023
    165.75 KB
    IntelliKnight System Sensor Device Specification Data Sheet
    application/pdf 266.36 KB
    5/14/2023
    266.36 KB
    SK-DUCT Intelligent Air Duct Smoke Detector-Data Sheet
    application/pdf 145.44 KB
    5/14/2023
    145.44 KB
    Name
    Description
    File Size
    Date
    Size
    SK-DUCT BIM File
    1.31 MB
    SK-DUCT-W BIM File
    740 KB
    SK-DUCT analog photoelectric duct smoke detector housings CSFM Listing
    165.75 KB
    5/14/2023
    IntelliKnight System Sensor Device Sell Sheet
    266.36 KB
    6/23/2022
    SK-Duct Addressable Photoelectric Duct Detector Manual
    1.05 MB
    5/8/2023
    IntelliKnight System Sensor Device Specification Data Sheet
    266.36 KB
    5/14/2023
    SK-DUCT Intelligent Air Duct Smoke Detector-Data Sheet
    145.44 KB
    5/14/2023
    Product Number
    Part Number
    Description
    Add to list
    SK-DUCT-W
    Intelligent non-relay photoelectric low flow smoke detector housing. Includes SK-PHOTO-R-W detector.
