Q5020 Globe Valve Linkages
The Q5020 Globe Valve Linkages connect a Honeywell direct coupled actuator (DCA) to a steam or water globe valve. The Q5020 Linkages are compatible with two-way and three-way globe valves up to 3 inch (DN80).
Please sign in to access more documents
Once signed in, you may be able to access additional documents for your account.
Overview
The Q5020 Globe Valve Linkages connect a Honeywell direct coupled actuator (DCA) to a steam or water globe valve. The Q5020 Linkages are compatible with two-way and three-way globe valves up to 3 inch (DN80).
Features & Benefits:- Used with two‑way and three‑way globe valves in modulating or two‑position service.
- Used with 25, 50, and 142 lb‑in. spring return and 35, 70, 150, and 300 lb‑in. non‑spring return DCA.
- Quick and simple installation with no disassembly required.
- Heavy‑duty Steel rack and pinion construction and Aluminum Die‑cast housing.
- Maintenance‑free construction.
- Precision roller‑bearing rack construction prevents premature valve packing wear and leakage.
- Flexible actuator mounting orientation.
- Adjustable manual override lever and valve position indicator.
- Can be mounted on specific non‑Honeywell valves using a 32004629 Bonnet Adapter Kit.
