Globe Valves
V5011R Series 2-Way Internal Thread Linear Control Valve PN16
The 2-way Control Globe Valves are a complete series of single-seated straight through globe control valves PN16. They are suitable for heating, ventilation and air conditioning systems (HVAC).
Overview
The 2-way Control Globe Valves are a complete series of single-seated straight through globe control valves PN16. They are suitable for heating, ventilation and air conditioning systems (HVAC). There are different order numbers for the 2-way straight through valve of the type V5011R. Depending on the flow capacity and the valve size, vary the last four digits of the order number.
Features & Benefits:- Brass body with internal threaded end connections
- Low seat leakage rate
- Self-adjusting packing
- Accurate positioning to ensure state-of-the-art temperature control
- Directly-coupled electric and pneumatic actuators for easy mounting
- ISO228
Specifications
Others
- Media Temperature Range
- 120 - 170 °C @ 1490 kPa
- 2 - 120 °C @ 1600 kPa
- Brand
- CentraLine
- Actuator Stroke Length
- 20 millimetre
- Nominal Pressure
- PN16 bar (air pressure)
- Port Connection
- Internal Thread
- Valve Series
- V5011R/S
Others
- Media Temperature Range
- 120 - 170 °C @ 1490 kPa
- 2 - 120 °C @ 1600 kPa
- Brand
- CentraLine
- Actuator Stroke Length
- 20 millimetre
- Nominal Pressure
- PN16 bar (air pressure)
- Port Connection
- Internal Thread
- Valve Series
- V5011R/S
- Media Temperature Range : 120 - 170 °C @ 1490 kPa|2 - 120 °C @ 1600 kPa
- Brand : CentraLine
- Actuator Stroke Length : 20 millimetre
- Nominal Pressure : PN16 bar (air pressure)
- Port Connection : Internal Thread
- Valve Series : V5011R/S
Others
Name
Description
File Size
Date
Size
V5011R DURCHGANGSVENTIL MIT INNENGEWINDE (DP) ROTGUSS, PN16
application/pdf 30.79 KB
5/14/2023
30.79 KB
FIELD DEVICES PRODUCT CATALOG 2020
application/pdf 3.03 MB
9/19/2023
3.03 MB
V5011R INTERNAL THREADED END-CONNECTION LINEAR VALVE PN16
application/pdf 191.13 KB
6/23/2023
191.13 KB
V5011R VALVULAS LINEALES DE CONEXION ROSCADA PN16
application/pdf 33.87 KB
5/14/2023
33.87 KB
V5011R VANNE A SIEGE 2-VOIES AVEC SORTIES TARAUDEES, PN16
application/pdf 80.82 KB
5/14/2023
80.82 KB
V5011R VALVOLA LINEARE CON ATTACCHI FILETTATI PN16
application/pdf 32.03 KB
5/14/2023
32.03 KB
Name
Description
File Size
Date
Size
V5011R DURCHGANGSVENTIL MIT INNENGEWINDE (DP) ROTGUSS, PN16
30.79 KB
5/14/2023
30.79 KB
V5011R INTERNAL THREADED END-CONNECTION LINEAR VALVE PN16
191.13 KB
6/23/2023
191.13 KB
V5011R VALVULAS LINEALES DE CONEXION ROSCADA PN16
33.87 KB
5/14/2023
33.87 KB
V5011R VANNE A SIEGE 2-VOIES AVEC SORTIES TARAUDEES, PN16
80.82 KB
5/14/2023
80.82 KB
V5011R VALVOLA LINEARE CON ATTACCHI FILETTATI PN16
32.03 KB
5/14/2023
32.03 KB
Name
Description
File Size
Date
Size
V5011R DURCHGANGSVENTIL MIT INNENGEWINDE (DP) ROTGUSS, PN16
30.79 KB
5/14/2023
V5011R INTERNAL THREADED END-CONNECTION LINEAR VALVE PN16
191.13 KB
6/23/2023
V5011R VALVULAS LINEALES DE CONEXION ROSCADA PN16
33.87 KB
5/14/2023
V5011R VANNE A SIEGE 2-VOIES AVEC SORTIES TARAUDEES, PN16
80.82 KB
5/14/2023
V5011R VALVOLA LINEARE CON ATTACCHI FILETTATI PN16
32.03 KB
5/14/2023
Product Number
SKUs
SKU
Description
V5011R1000
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 0.63, DN15, 20mm stroke
V5011R1018
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 1.0, DN15, 20mm stroke
V5011R1026
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 1.6, DN15, 20mm stroke
V5011R1034
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 2.5, DN15, 20mm stroke
V5011R1042
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 4.0, DN15, 20mm stroke
V5011R1059
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 6.3, DN20, 20mm stroke
V5011R1067
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 10, DN25, 20mm stroke
V5011R1075
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 16, DN32, 20mm stroke
V5011R1083
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 25, DN40, 20mm stroke
V5011R1091
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 40, DN50, 20mm stroke
SKU
Description
V5011R1000
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 0.63, DN15, 20mm stroke
V5011R1018
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 1.0, DN15, 20mm stroke
V5011R1026
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 1.6, DN15, 20mm stroke
V5011R1034
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 2.5, DN15, 20mm stroke
V5011R1042
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 4.0, DN15, 20mm stroke
V5011R1059
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 6.3, DN20, 20mm stroke
V5011R1067
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 10, DN25, 20mm stroke
V5011R1075
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 16, DN32, 20mm stroke
V5011R1083
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 25, DN40, 20mm stroke
V5011R1091
2-Way Linear Valve, Internal Thread Connection, PN16, KVs 40, DN50, 20mm stroke
